Röle - PANASONIC JS1-B-5V-FT POWER 10A 5VDC ULTRA MINI PCB TYPE

Series JS Coil Type Non Latching Manufacturer PANASONIC COMP. Coil Current 72mA Height 16.00mm Coil Power 360mW Length 22.00mm Rohs ROHS Mounting Type THT Coil Voltage 5VDC Contact Voltage 250VAC/30VDC Operating Temperature -40°C~+85°C Width 16.00mm Packaging TRAY Relay Type Relay Power Contact Form SPDT (1 Form C) Contact Current (Nom) 6A Contact Current (Max) 10A Coil Resistance 69.40 Ohms Number of Pins 5 Pin
